2PB709ART
Nexperia
45 V, 100 mA PNP general-purpose transistor
10. Soldering
2.90
2.50
2
1
0.85
0.85
solder lands
3.00
1.30
2.70
solder resist
solder paste
3
occupied area
0.60
(3x)
Dimensions in mm
0.50 (3x)
0.60 (3x)
1.00
3.30
sot023
Fig 8. Reflow soldering footprint SOT23 (TO-236AB)
3.40
1.20 (2x)
solder lands
solder resist
occupied area
2
1
4.60 4.00 1.20
3
Dimensions in mm
preferred transport direction during soldering
sot023
2.80
4.50
Fig 9. Wave soldering footprint SOT23 (TO-236AB)
2PB709ART
© Nexperia B.V. 2007. All rights reserved.
Product data sheet
Rev. 01 — 19 March 2007
7 of 10
