µPD178023, 178024
• When in-circuit emulator IE-78001-R-A is used
IE-78001-R-A
In-circuit emulator common to 78K/0 series
Interface adapter necessary when a PC-9800 series (except notebook-type PC) is used as host
IE-70000-98-IF-C
machine (C bus supported)
IE-70000-PC-IF-C
IE-70000-PCI-IF
IE-78000-R-SV3
IE-178134-NS-EM1Note4
IE-78K0-R-EX1
EP-78130GF-R
EV-9200G-80
Interface adapter when a IBM PC/AT compatible machine is used (ISA bus supported)
Interface adapter necessary when a PC with a PCI bus is used as host machine
Interface adapter and cable necessary when an EWS is used as host machine
Emulation board for emulating the µPD178024 subseries
Emulation probe conversion board necessary when using IE-178134-NS-EM1 on IE-78001-R-A.
Emulation probe for 80-pin plastic QFP (GF-3B9 type)
Socket to be mounted on the board of the target system for 80-pin plastic QFP (GF-3B9 type)
Emulation probe for 80-pin plastic QFP (GC-8BT type)
EP-78230GC-R
EV-9200GC-80
SM78K0Notes 1, 2
ID78K0Notes 1, 2
Socket to be mounted on the board of the target system for 80-pin plastic QFP (GC-8BT type)
System simulator common to 78K/0 series
Integrated debugger common to 78K/0 series
DF178124Notes 1, 2, 3
Device file for µPD178024 subseries
Real-time OS
RX78K0Notes 1, 2, 3
MX78K0Notes 1, 2, 3
Real-time OS for 78K/0 series
OS for 78K/0 series
Notes 1. PC-9800 series (MS-DOS + Windows) based
2. IBM PC/AT compatible machine (Japanese/English windows) based
3. HP9000 series 700 (HP-UX) based, SPARCstation (SunOS, Solaris) based, NEWS (NEW-OS) based
4. Under development
Remark Use SM78K0 in combination with the DF178124.
48
Data Sheet U14126EJ1V0DS00
