APPENDIX A DEVELOPMENT TOOLS
A.3 Debugging Tools
A.3.1 Hardware
IE-78K0S-NS
In-circuit emulator for debugging hardware and software of application system using 78K/0S
Series. Supports integrated debugger (ID78K0S-NS). Used in combination with AC adapter,
emulation probe, and interface adapter for connecting the host machine.
In-circuit emulator
IE-70000-MC-PS-B
AC adapter
Adapter for supplying power from AC 100 to 240 V outlet.
IE-70000-98-IF-C
Interface adapter
Adapter necessary when using PC-9800 series PC (except notebook type) as host machine of
IE-78K0S-NS (C bus supported)
IE-70000-CD-IF-A
PC card interface
PC card and interface cable necessary when using notebook PC as host machine of IE-78K0S-
NS (PCMCIA socket supported)
IE-70000-PC-IF-C
Interface adapter
Interface adapter necessary when using IBM PC/AT compatible as host machine of IE-78K0S-
NS (ISA bus supported)
IE-70000-PCI-IF
Interface adapter
Adapter necessary when using personal computer incorporating PCI bus as host machine of IE-
78K0S-NS
IE-789456-NS-EM1
Emulation board
Board for emulating the peripheral hardware inherent to the device. Used in combination with in-
circuit emulator.
NP-64GK
Probe to connect the in-circuit emulator and target system.
Used in combination with the TGK-064SBW and TGK-064SBP.
Emulation probe
TGK-064SBW, Conversion socket to connect the NP-64GK and a target system board on which a 64-pin plastic
TGK-064SBP
Conversion
adapter
TQFP (fine pitch) (GK-9ET type) can be mounted
Remarks 1. The NP-64GK is a product made by Naito Densei Machida Mfg. Co., Ltd. (TEL +81-44-822-3813).
2. The TGK-064SBW and TGK-064SBP are products made by TOKYO ELETECH CORPORATION.
For further information, contact: Daimaru Kogyo, Ltd.
Tokyo Electronics Department (TEL +81-3-3820-7112)
Osaka Electronics Department (TEL +81-6-6244-6672)
User’s Manual U15075EJ1V0UM00
313
