APPENDIX A DEVELOPMENT TOOLS
A.1 Language Processing Software
RA78K0S
Program that converts program written in mnemonic into object codes that can be executed
by microcontroller.
Assembler package
In addition, automatic functions to generate symbol table and optimize branch instructions
are also provided.
Used in combination with optional device file (DF789456).
<Caution when used under PC environment>
The assembler package is a DOS-based application but may be used under the Windows
environment by using Project Manager of Windows (included in the assembler package).
Part number: µS××××RA78K0S
CC78K0S
Program that converts program written in C language into object codes that can be
executed by microcontroller.
C compiler package
Used in combination with optional assembler package (RA78K0S) and device file
(DF789316).
<Caution when used under PC environment>
The C compiler package is a DOS-based application but may be used under the Windows
environment by using Project Manager of Windows (included in the assembler package).
Part number: µS××××CC78K0S
DF789456Note
Device file
File containing the information inherent to the device.
Used in combination with optional RA78K0S, CC78K0S, and SM78K0S.
Part number: µS××××DF789456
CC78K0S-L
Source file of functions for generating object library included in C compiler package.
Necessary for changing object library included in C compiler package according to
customer’s specifications. Since this is a source file, its working environment does not
depend on any particular operating system.
C compiler source file
Part number: µS××××CC78K0S-L
Note DF789456 is a common file that can be used with RA78K0S, CC78K0S, and SM78K0S.
Remark ×××× in the part number differs depending on the host machines and operating systems to be used.
µS××××RA78K0S
µS××××CC78K0S
µS××××DF789456
µS××××CC78K0S-L
××××
AA13
AB13
BB13
3P16
3K13
3K15
3R13
Host Machine
PC-9800 series
OS
Supply Media
3.5" 2HD FD
Japanese WindowsNote
Japanese WindowsNote
English WindowsNote
HP-UXTM (Rel. 10.10)
SunOSTM (Rel. 4.1.1),
SolarisTM (Rel. 2.5.1)
IBM PC/AT compatibles
3.5" 2HC FD
HP9000 series 700TM
SPARCstationTM
DAT (DDS)
3.5" 2HC FD
1/4" CGMT
3.5" 2HC FD
NEWSTM (RISC)
NEWS-OSTM (Rel. 6.1)
Note Also operates under the DOS environment.
User’s Manual U15075EJ1V0UM00
311
