DDR3(L)-2Gb SDRAM
NT5CB(C)256M8JQ/NT5CB(C)128M16JR
DLL-off mode READ Timing Operation
T0
T1
T2
T3
T4
T5
T6
T7
T8
T9
CK
CK
CMD
Address
READ
Bank, Col b
RL = AL+CL = 6 (CL=6, AL=0)
DQSdiff_DLL_on
DQ_DLL_on
Din
b
Din
b+1
Din
b+2
Din
b+3
Din
b+4
Din
b+5
Din
b+6
Din
b+7
RL(DLL_off) = AL+(CL-1) = 5
tDQSCKDLL_diff_min
DQSdiff_DLL_off
Din
b+4
Din
b
Din
b+1
Din
b+2
Din
b+3
Din
b+5
Din
b+6
Din
b+7
DQ_DLL_off
DQSdiff_DLL_off
tDQSCKDLL_diff_max
Din
b+4
Din
b
Din
b+1
Din
b+2
Din
b+3
Din
b+5
Din
b+6
Din
b+7
DQ_DLL_off
Note: The tDQSCK is used here for DQS, , and DQ to have a simplified diagram; the DLL_off shift will affect both timings in the same
way and the skew between all DQ, DQS, and signals will still be tDQSQ.
Version 1.4
05/2019
32
Nanya Technology Cooperation ©
All Rights Reserved.
