■ Package
Tape Carrier Packaging
1.
Minimum Quantity (pcs./reel)
φ180mm Reel
φ180mm Reel
PAPER Tape
Code:W
φ330mm Reel
PAPER Tape
Code:J
Series
PAPER Tape
Code:D
GRM15
10000(W8P2)
20000(W8P1)
50000(W8P2)
5
2. Dimensions of Tape (in mm)
(1)GRM155(W8P2 Code:D/J)
G
H
J
E
D
A
B
C
M
F
K
Dimensions(Chip)
W
Series
A
B
C
D
E
F
G
H
J
K
L
-
M
L
T
0.5+/-0.05
GRM15
1.0+/-0.05
0.5+/-0.05
0.65(Typ.)
1.15(Typ.)
8.0+/-0.3
3.5+/-0.05
1.75+/-0.1
2.0+/-0.05
2.0+/-0.05
4.0+/-0.1
φ1.5+0.1/-0
0.8 max.
0.05 max.
5
(2)GRM155(W8P1 Code:W)
G
H
J
E
D
C
A
B
F
K
Dimensions(Chip)
W
Series
L
A
B
C
D
E
F
G
H
J
K
L
-
M
-
T
0.5+/-0.05
GRM15
1.0+/-0.05
0.5+/-0.05
0.65(Typ.)
1.15(Typ.)
8.0+/-0.3
3.5+/-0.05
1.75+/-0.1
1.0+/-0.05
1.0+/-0.05
4.0+/-0.1
φ1.5+0.1/-0
0.8 max.
5
