Please read CAUTION and Notice in this catalog for safety. This catalog has only typical specifications. Therefore you are requested
to approve our product specification or to transact the approval sheet for product specification, before your ordering.
P61E7.pdf 01.10.17
■ Standard Land Pattern Dimensions
■ Test Circuit
(3)
(2)
R1
(4)
(1)
(4)
2
Rg
E1
R2
C2
E2
RF
Voltmeter
S.S.G.
=-10dBm
(1)
(2)
(3)
0.1
0.1
Rg=50Ω
(1) : Input
R1=280Ω
R2=330Ω
C2=10pF
(2) : Ground
(3) : Float
(4) : Output
0.8 0.6 0.8 0.6 0.8
(1) : Input (2) : Ground (3) : Float Signal Line (4) : Out put
It shows solder resist land pattern.
(Including stray capacitance
and Input capacitance of RF Voltmeter)
(in mm)
9
