GNM Series Specifications and Test Methods (1)
In case Non "*" is added in PNs table, please refer to GNM Series Specifications and Test Methods (1).
In case "*" is added in PNs table, please refer to GNM Series Specifications and Test Methods (2).
Specifications
2
No.
1
Item
Test Method
Temperature
Compensating Type
High Dielectric Type
Operating
Temperature
Range
R7, C7: –55 to +125°C
R6: –55 to +85°C
5C: –55 to +125°C
The rated voltage is defined as the maximum voltage which
may be applied continuously to the capacitor.
When AC voltage is superimposed on DC voltage, VP-P or VO-P
whichever is larger, should be maintained within the rated
voltage range.
2
Rated Voltage
See the previous pages.
,
3
4
Appearance
Dimensions
No defects or abnormalities
Visual inspection
Using calipers
Within the specified dimensions
No failure should be observed when 300% of the rated voltage
(5C) or 250% of the rated voltage (R7) is applied between the
terminations for 1 to 5 seconds, provided the charge/discharge
current is less than 50mA.
5
Dielectric Strength No defects or abnormalities
The insulation resistance should be measured with a DC
voltage not exceeding the rated voltage at 25°C and 75%RH
max. and within 2 minutes of charging.
Insulation
Resistance
More than 10,000MΩ or 500Ω · F
(Whichever is smaller)
6
7
Capacitance
Within the specified tolerance
The capacitance/Q/D.F. should be measured at 25°C at the
30pF min.: QU1000
frequency and voltage shown in the table.
30pF max.:
Char.
Q/
Char. 25V min. 16V
R7, R6, 0.025 0.035 0.035 0.05
C7 max. max. max. max.
10V
6.3V
5C
R7
QU400+20C
Item
8
Dissipation Factor
(D.F.)
Frequency
Voltage
1±0.1MHz
0.5 to 5Vrms
1±0.1kHz
1.0±0.2Vrms
C: Nominal
Capacitance (pF)
The capacitance change should be measured after 5 min. at
each specified temperature stage.
(1) Temperature Compensating Type
Temp. Reference
Cap.
Change
Char.
Range
Temp.
–55°C
to +125°C
Within the
specified tolerance
(Table A)
R7
R6
C7
The temperature coefficient is determined using the capaci-
tance measured in step 3 as a reference. When cycling the
temperature sequentially from step1 through 5, the capacitance
should be within the specified tolerance for the temperature
coefficient and capacitance change as Table A.
The capacitance drift is calculated by dividing the differences
between the maximum and minimum measured values in the
steps 1, 3 and 5 by the cap. value in step 3.
Capacitance
Change
Within
±15%
–55°C
to +85°C
25°C
–55°C
to +125°C
Within
±22%
Within the
specified tolerance
(Table A)
Temperature
Coefficient
Capacitance
Step
Temperature (°C)
1
2
3
4
5
25±2
9
Temperature
–55±3 (for 5C/R7/C7), –30±3 (for F5)
Characteristics
25±2
125±3 (for 5C/R7/C7), 85±3 (for F5)
25±2
(2) High Dielectric Constant Type
Within ±0.2%
or ±0.05pF
(Whichever is
larger.)
The ranges of capacitance change compared with the above
25°C value over the temperature ranges shown in the table
should be within the specified ranges.
Capacitance
Drift
• Initial measurement for high dielectric constant type.
Perform a heat treatment at 150+0/-10°C for one hour and
then set for 24±2 hours at room temperature.
Perform the initial measurement.
No removal of the terminations or other defect should occur.
Solder the capacitor to the test jig (glass epoxy board) shown in
Fig.1 using a eutectic solder. Then apply 5N force in parallel with
the test jig for 10±1 sec.
GNMpp4
GNMpp2
b
a
b
a
The soldering should be done either with an iron or using the
reflow method and should be conducted with care so that the
soldering is uniform and free of defects such as heat shock.
Adhesive Strength
of Termination
Type
a
b
c
d
0.32
0.5
0.25
0.4
10
GNM1M2
GNM212
GNM214
GNM314
0.5
0.6
0.6
0.8
1.6
1.8
2.0
2.5
0.32
0.5
0.25
0.4
Solder resist
Copper foil
Solder resist
Copper foil
(in mm)
Fig. 1
Continued on the following page.
