High Dielectric Constant Type X5R(R6) Characteristics
LxW [mm]
0.9x0.6(0M)<0302>
2(2)
2
Number of Elements
Rated Volt. [Vdc]
16(1C)
10(1A)
6.3(0J)
4(0G)
Capacitance
10000pF(103)
22000pF(223)
47000pF(473)
0.10µF(104)
1.0µF(105)
Tolerance
Part Number
±20% (M)
±20% (M)
±20% (M)
±20% (M)
±20% (M)
GNM0M2R61C103ME18D* GNM0M2R61A103ME17D* GNM0M2R60J103ME17D*
GNM0M2R61C223ME18D* GNM0M2R61A223ME17D* GNM0M2R60J223ME17D*
GNM0M2R61C473ME18D* GNM0M2R61A473ME17D* GNM0M2R60J473ME17D*
GNM0M2R61C104ME18D* GNM0M2R61A104ME17D* GNM0M2R60J104ME17D*
GNM0M2R60G105ME17D*
LxW [mm]
1.37x1.0(1M)<0504>
2(2)
Number of Elements
Rated Volt. [Vdc]
50(1H)
25(1E)
16(1C)
Capacitance
1000pF(102)
Tolerance
Part Number
±20% (M)
±20% (M)
±20% (M)
±20% (M)
±20% (M)
±20% (M)
±20% (M)
±20% (M)
GNM1M2R61H102MA01D
2200pF(222)
4700pF(472)
10000pF(103)
22000pF(223)
47000pF(473)
0.22µF(224)
1.0µF(105)
GNM1M2R61E222MA01D
GNM1M2R61E472MA01D
GNM1M2R61E103MA01D
GNM1M2R61C223MA01D
GNM1M2R61C473MA01D
GNM1M2R61C224ME18D*
GNM1M2R61C105ME18D*
LxW [mm]
1.37x1.0(1M)<0504>
Number of Elements
Rated Volt. [Vdc]
2(2)
10(1A)
6.3(0J)
Capacitance
22000pF(223)
47000pF(473)
0.10µF(104)
1.0µF(105)
Tolerance
Part Number
±20% (M)
±20% (M)
±20% (M)
±20% (M)
±20% (M)
GNM1M2R61A223MA01D
GNM1M2R61A473MA01D
GNM1M2R61A104MA01D
GNM1M2R61A105ME17D* GNM1M2R60J105ME12D*
GNM1M2R61A225ME18D* GNM1M2R60J225ME18D*
2.2µF(225)
LxW [mm]
2.0x1.25(21)<0805>
2(2)
Number of Elements
Rated Volt. [Vdc]
16(1C)
10(1A)
6.3(0J)
Capacitance
0.47µF(474)
Tolerance
Part Number
±20% (M)
±20% (M)
±20% (M)
GNM212R61C474MA16D
GNM212R61C105MA16D
1.0µF(105)
2.2µF(225)
GNM212R61A105MA13D
GNM212R61A225ME16D* GNM212R60J225ME16D*
The part number code is shown in ( ) and Unit is shown in [ ].
*: Please refer to GNM series Specifications and Test Method(2).
< >: EIA [inch] Code
qProduct ID
wSeries
tTemperature Characteristics
iCapacitance Tolerance
eDimension (LxW)
yRated Voltage
oIndividual Specification Code !Packaging
rNumber of Elements
uCapacitance
(Part Number) GN
M
0M
2
R6 1C 103
M
E18
D
q
w
e
r
t
y
u
i
o
!
Packaging Code in Part Number is a code shows STD Tray.
