Package
Continued from the preceding page.
(3) Dimensions of Embossed Tape
4mm width 1mm pitch Tape
8mm width 4mm pitch Tape
0.2±0.1 (LLp)
0.25±0.1 (TV2.0mm)
0.3±0.1 (T=2.5mm)
2.0±0.04
4.0±0.1
1.0±0.02
+0.1
-0
2.0±0.1
ø1.5
4.0±0.1
1.0±0.02
0.15 to 0.4
1.75±0.1
ø0.8±0.04
A
A
0.5 max.
Direction of feed
2.5 max.
(3.0 max. for T=1.8/2.0mm)
Part Number
A*
B*
(3.7 max. for TU2.5mm)
0.23
0.43
GRM02
Part Number
A
B
*Nominal Value
1.05±0.1
1.45±0.2
1.55±0.2
1.85±0.1
LLL18, LLA18
*GRM03 is also available by 4mm width 1mm pitch Tape.
GRM21
(TU1.0mm)
LLL21
2.25±0.2
2.3±0.2
12mm width 8mm pitch Tape
LLA21, LLM21
+0.1
-0
ø1.5
ERB21
8.0±0.1 2.0±0.1
4.0
0.3±0.1
1.75±0.1
8
±
0.1
GRM31
(TU1.15mm)
LLL31
LLA31, LLM31
GNM31
(TU1.0mm)
1.9±0.2
2.8±0.2
3.5±0.2
3.5±0.2
A
GRM32, ERB32
(TU1.0mm)
Direction of feed
2.5 max.
for GRM43/55
(3.7 max. for T=2.5mm)
(4.7 max. for TU3.0mm)
Part Number
A*
3.6
5.2
B*
4.9
6.1
GRM43
GRM55
*Nominal Value
(in mm)
(4) Taping Method
q Tapes for capacitors are wound clockwise. The
sprocket holes are to the right as the tape is pulled
toward the user.
Vacant Section Chip-mounting Unit Vacant Section
Leader unit
w Part of the leader and part of the empty tape should be
attached to the end of the tape as follows.
e The top tape and base tape are not attached at the
end of the tape for a minimum of 5 pitches.
r Missing capacitors number within 0.1% of the number
per reel or 1 pc, whichever is greater, and are not
continuous.
160 min.
190 min.
210 min.
(Top Tape alone)
Direction of Feed
(in mm)
t The top tape and bottom tape should not protrude
beyond the edges of the tape and should not cover
sprocket holes.
y Cumulative tolerance of sprocket holes, 10 pitches:
±0.3mm.
Top Tape
u Peeling off force: 0.1 to 0.6N* in the direction shown
below.
*GRM02
GRM03
GJM03
GMD03
Base Tape
: 0.05 to 0.5N
}
Continued on the following page.
138
