Package
Continued from the preceding page.
■ Tape Carrier Packaging
(1) Dimensions of Reel
ø180mm Reel
ø330mm Reel
2.0±0.5
ø13.0±0.5
2.0±0.5
ø13.0±0.5
ø21.0±0.8
ø21.0±0.8
5±1.5 for 4mm wide tape
10±1.5 for 8mm wide tape
14±1.5 for 12mm wide tape
10±1.5 for 8mm wide tape
14±1.5 for 12mm wide tape
(in mm)
8
(2) Dimensions of Paper Tape
8mm width 4mm pitch Tape
8mm width 2mm pitch Tape
0.4 max.
(GRM02)
0.5 max.
(GJM03/GRM03/GMD03)
0.8 max.
(GJM15/GRM15/GMD15
LLL15/GNM0M)
4.0±0.1
4.0±0.1
2.0±0.1
4.0±0.1
ø1.5+0.1
-0
1.75±0.1
ø1.5+-0.1
2.0±0.05
1.1 max.
2.0±0.1
0
1.75±0.1
A
A
Direction of Feed
Direction of Feed
Part Number
A
B
Part Number
A*
B*
GRM18
GQM18
ERB18
GRM02
0.25
0.45
1.05±0.1
1.17±0.05
1.85±0.1
GJM03
GRM03
GMD03
0.37
0.67
1.55±0.05
GNM1M
GJM15
GRM15
GMD15
LLL15
GRM21
(TV0.85mm)
GQM21
0.65
0.72
1.15
1.55±0.15
2.3±0.15
GNM21
1.02
GNM0M
GRM31
(TV0.85mm)
GNM31
*Nominal Value
2.0±0.2
2.8±0.2
3.6±0.2
3.6±0.2
(TV0.8mm)
GRM32
(TV0.85mm)
(in mm)
Continued on the following page.
