Temperature Compensating Type C0G(5C) Characteristics
LxW [mm]
2.0x1.25(21)<0805>
Rated Volt. [Vdc]
Capacitance
43pF(430)
250(2E)
50(1H)
Tolerance
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
Part Number
GQM2195C2E430GB12D
GQM2195C2E430JB12D
GQM2195C2E470GB12D
GQM2195C2E470JB12D
GQM2195C2E510GB12D
GQM2195C2E510JB12D
GQM2195C2E560GB12D
GQM2195C2E560JB12D
GQM2195C2E620GB12D
GQM2195C2E620JB12D
GQM2195C2E680GB12D
GQM2195C2E680JB12D
GQM2195C2E750GB12D
GQM2195C2E750JB12D
GQM2195C2E820GB12D
GQM2195C2E820JB12D
GQM2195C2E910GB12D
GQM2195C2E910JB12D
GQM2195C2E101GB12D
GQM2195C2E101JB12D
GQM2195C1H430GB01D
GQM2195C1H430JB01D
GQM2195C1H470GB01D
GQM2195C1H470JB01D
GQM2195C1H510GB01D
GQM2195C1H510JB01D
GQM2195C1H560GB01D
GQM2195C1H560JB01D
GQM2195C1H620GB01D
GQM2195C1H620JB01D
GQM2195C1H680GB01D
GQM2195C1H680JB01D
GQM2195C1H750GB01D
GQM2195C1H750JB01D
GQM2195C1H820GB01D
GQM2195C1H820JB01D
GQM2195C1H910GB01D
GQM2195C1H910JB01D
GQM2195C1H101GB01D
GQM2195C1H101JB01D
47pF(470)
51pF(510)
56pF(560)
62pF(620)
68pF(680)
75pF(750)
82pF(820)
91pF(910)
100pF(101)
5
The part number code is shown in ( ) and Unit is shown in [ ].
< >: EIA [inch] Code
qProduct ID
tTemperature Characteristics
iCapacitance Tolerance
wSeries
eDimension (LxW)
yRated Voltage
oIndividual Specification Code !Packaging
rDimension (T)
uCapacitance
(Part Number) GQ
M
21
9
5C 2E 430
G
B12
D
q
w
e
r
t
y
u
i
o
!
Packaging Code in Part Number is a code shows STD 180mm Reel Taping.
