Safety Certified Ceramic Capacitors for Automotive Packaging
■ Taping Specifications
15mm pitch / lead spacing 7.5mm taping
Vertical crimp type
(Lead Code: N3)
∆S
O
∆h1
∆h2
P2
P
D
T max.
Marked side
ød
P1
F
3.0 max.
H0
øD0
R
P0
t2
t1
Item
Code
P
N3
15.0±2.0
15.0±0.3
7.5±1.0
Pitch of component
Pitch of sprocket hole
Lead spacing
P0
F
P2
P1
D
7.5±1.5
Length from hole center to component center
Length from hole center to lead
Body diameter
3.75±1.0
See the individual product specifications.
∆S
W
0±2.0
Deviation along tape, left or right
Carrier tape width
18.0±0.5
W1
H0
r
øD0
ød
t1
9.0±0.5
Position of sprocket hole
+2.0
Lead distance between reference and bottom planes
Protrusion length
18.0
–0
+0.5 to -1.0
4.0±0.1
Diameter of sprocket hole
Lead diameter
0.6±0.05
0.6±0.3
Total tape thickness
t2
1.5 max.
7.0 max.
Total thickness, tape and lead wire
Body thickness
T
+0
L
11.0
Portion to cut in case of defect
Hold down tape width
–1.0
W0
W2
e
11.5 min.
1.5±1.5
Hold down tape position
Coating extension on lead
Deviation across tape, front
Deviation across tape, rear
Up to the end of crimp
∆h1
∆h2
2.0 max.
(in mm)
12
■ Packaging Styles
■ Minimum Quantity (Order in Sets Only)
[Bulk]
(pcs./Bag)
Lead Code
B3
Bulk
Taping
Lead Code
A3
Polyethylene Bag
Ammo Pack
Body Dia. D
(mm)
Long
250
Short
500
7 to 10
12
200
250
[Taping]
Lead Code: N3
700pcs./Ammo Pack
75
