Safety Standard Certified Ceramic Capacitors
Type KX Small Size (Reinforced Insulation) -IEC60384-14 Class X1, Y1-
D max.
T max.
■ Features
1. We design capacitors much more compact in size than
current Type KX, having reduced the diameter
by 20% max.
3
e
2. Operating temperature range guaranteed up to 125
degrees (UL: 85 deg.).
F±1.0
3. Dielectric strength: AC4000V
ød
4. Class X1/Y1 capacitors certified by
UL/CSA/VDE/BSI/SEMKO/DEMKO/FIMKO/NEMKO/ESTI/
IMQ.
(in mm)
[Bulk]
Lead Code
Coating Extension e
ød
Vertical Crimp Long (A4)
Up to the end of crimp
0.6±0.05
A4
5. Can be use with a component in appliances
requiring reinforced insulation and double
insulation based on UL1492, IEC60065 and IEC60950.
6. Coated with flame-retardant epoxy resin (conforming
to UL94V-0 standard).
D max.
T max.
Please contact us when a halogen-free product*
is necessary.
e
* Cl=900ppm max., Br=900ppm max. and
Cl+Br=1500ppm max.
ød
F±0.8
7. Taping available for automatic insertion.
(in mm)
■ Applications
[Bulk]
Lead Code
Coating Extension e
ød
Vertical Crimp Short (B4)
Up to the end of crimp
0.6±0.05
B4
1. Ideal for use as X/Y capacitors for AC line filters
and primary-secondary coupling on switching power
supplies and AC adapters.
2. Ideal for use on D-A isolation and noise absorption
for DAA modems without transformers.
Do not use these products in any automotive
power train or safety equipment including battery
chargers for electric vehicles and plug-in hybrids.
Only Murata products clearly stipulated as
"for Automotive use" on its catalog can be used
for automobile applications such as power train and
safety equipment.
*: Small sized Type KX differs from current Type KX
in electrical characteristics, such as the voltage
dependency, capacitance temperature dependency,
and Dielectric strength.
Therefore, before replacing current Type KX,
please make a performance check by equipment.
Please also refer to Notice (Rating) item 2,
"Performance Check by Equipment," below.
