AC Rated
Voltage
(Vac)
Body
Dia. D
(mm)
Lead
Body
Lead
Lead
Lead
Temp.
Char.
Capacitance
(pF)
Part Number
Spacing F Thickness T Package
Package
Package
(mm)
(mm)
Long Bulk Short Bulk Taping (1)
DE2B3KH101Kppp
DE2B3KH151Kppp
DE2B3KH221Kppp
DE2B3KH331Kppp
DE2B3KH471Kppp
DE2B3KH681Kppp
DE2E3KH102Mppp
DE2E3KH152Mppp
DE2E3KH222Mppp
DE2E3KH332Mppp
DE2E3KH472Mppp
DE2F3KH103Mppp
250
250
250
250
250
250
250
250
250
250
250
250
B
B
B
B
B
B
E
E
E
E
E
F
100 ±10%
150 ±10%
220 ±10%
330 ±10%
470 ±10%
680 ±10%
1000 ±20%
1500 ±20%
2200 ±20%
3300 ±20%
4700 ±20%
10000 ±20%
8 max.
8 max.
8 max.
8 max.
8 max.
9 max.
8 max.
9 max.
10 max.
12 max.
13 max.
16 max.
7.5
7.0 max.
A3B
A3B
A3B
A3B
A3B
A3B
A3B
A3B
A3B
A3B
A3B
A3B
B3B
B3B
B3B
B3B
B3B
B3B
B3B
B3B
B3B
B3B
B3B
B3B
N3A
N3A
N3A
N3A
N3A
N3A
N3A
N3A
N3A
N3A
N3A
N7A
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.0 max.
7.0 max.
7.0 max.
7.0 max.
7.0 max.
7.0 max.
7.0 max.
7.0 max.
7.0 max.
7.0 max.
7.0 max.
2
Three blank columns are filled with the lead and packaging codes. Please refer to the 3 columns on the right for the appropriate code.
Murata part numbers might be changed depending on lead code or any other changes. Therefore, please specify only the type name (KH) and capacitance of products
in the parts list when it is required for applying safety standard of electric equipment.
