WRITE: Writes access the eight bits of the write-only MI Bus transmit
data register. MI Bus devices require a 5-bit data pattern followed by
a 3-bit address pattern to be sent during the push field. The data
pattern is mapped to the lowest five bits of the data register and the
address to the highest three bits, as shown in the above table. Thus
MI-data[4:0] is written to SC0DRL[4:0] and MI-address[2:0] is written
to SC0DRL[7:5].
