Clock Functions
Bit 7
6
5
4
3
DISR
0
2
CR2
1
1
CR1
1
Bit 0
CR0
1
CME
FCME
FCMCOP
WCOP
RESET:
RESET:
0/1
0/1
0
0
0
0
0
0
Normal
Special
1
1
1
1
COPCTL — COP Control Register
$0016
CME — Clock Monitor Enable
Read and write anytime.
If FCME is set, this bit has no meaning nor effect.
0 = Clock monitor is disabled. Slow clocks and stop instruction may
be used.
1 = Slow or stopped clocks (including the stop instruction) will
cause a clock reset sequence or limp-home mode. See Limp-
Home and Fast STOP Recovery modes.
On reset
CME is 1 if VDDPLL is high
CME is 0 if VDDPLL is low.
NOTE: The VDDPLL-dependent reset operation is not implemented on first
pass products.
In this case the state of CME on reset is 0.
FCME — Force Clock Monitor Enable
Write once in normal modes, anytime in special modes. Read
anytime.
In normal modes, when this bit is set, the clock monitor function
cannot be disabled until a reset occurs.
0 = Clock monitor follows the state of the CME bit.
1 = Slow or stopped clocks will cause a clock reset sequence or
limp-home mode.
See Limp-Home and Fast STOP Recovery modes.
