Hawk Discrete Wire Termination Machine
1.7
Installation
WARNING:
When servicing this machine,
disconnect this power cord to insure complete
safety to service person.
Air Connection
Foot Pedal
Connect the 5-pin DIN plug on the foot pedal to the
5-pin socket in the right side of the terminator control
assembly.
Note the locking action of the plug.
Power Connection
A power cord is supplied for standard 110VAC
service. It is installed into the control box; plug the
other end into a grounded outlet.
The Hawk Discrete Wire Termination Machine will
operate on 110VAC or 220VAC, 50 or 60 Hz.
Because there are so many variations in air
connections, Molex does not supply any type of
fitting for air installation.
The user must supply a fitting of his choice to attach
air of the correct pressure and volume to the 1/4
NPT port on the F-R-L unit. Use 1/4 inch line
minimum. Once attached, adjust the regulator on
the F-R-L to 80-85psig. Air will not flow into the
machine proper until power is on and the "RESET"
button is pressed.
CYCLE COUNTER
CIRCUIT SIZE
ALARM
INDICATOR
POWER ON
BUTTON
RESET
BUTTON
Figure 1-2
PAWL RELEASE
Order No TM-011200949
Revision: D
Release Date: 02-16-97
Revision Date: 03-03-11
UNCONTROLLED COPY
Page 7 of 39
