Mitsubishi microcomputers
M16C / 61 Group
Serial I/O
SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER
UARTi transmit/receive control register 1
b7 b6 b5 b4 b3 b2 b1 b0
Symbol
UiC1(i=0,1)
Address
03A516,03AD16
When reset
0216
Function
(During clock synchronous
serial I/O mode)
Bit
symbol
Function
(During UART mode)
Bit name
R W
TE
Transmit enable bit
0 : Transmission disabled
1 : Transmission enabled
0 : Transmission disabled
1 : Transmission enabled
TI
Transmit buffer
empty flag
0 : Data present in
0 : Data present in
transmit buffer register
1 : No data present in
transmit buffer register
transmit buffer register
1 : No data present in
transmit buffer register
RE
RI
Receive enable bit
0 : Reception disabled
1 : Reception enabled
0 : Reception disabled
1 : Reception enabled
Receive complete flag
0 : No data present in
receive buffer register
1 : Data present in
0 : No data present in
receive buffer register
1 : Data present in
receive buffer register
receive buffer register
Nothing is assigned.
In an attempt to write to these bits, write “0”. The value, if read, turns out to be “0”.
UART2 transmit/receive control register 1
b7 b6 b5 b4 b3 b2 b1 b0
Symbol
U2C1
Address
037D16
When reset
0216
Function
(During clock synchronous
serial I/O mode)
Bit
Function
(During UART mode)
Bit name
symbol
R W
TE
TI
Transmit enable bit
0 : Transmission disabled
1 : Transmission enabled
0 : Transmission disabled
1 : Transmission enabled
Transmit buffer
empty flag
0 : Data present in
0 : Data present in
transmit buffer register
1 : No data present in
transmit buffer register
transmit buffer register
1 : No data present in
transmit buffer register
RE
RI
Receive enable bit
0 : Reception disabled
1 : Reception enabled
0 : Reception disabled
1 : Reception enabled
Receive complete flag
0 : No data present in
receive buffer register
1 : Data present in
0 : No data present in
receive buffer register
1 : Data present in
receive buffer register
receive buffer register
U2IRS UART2 transmit interrupt 0 : Transmit buffer empty
0 : Transmit buffer empty
(TI = 1)
cause select bit
(TI = 1)
1 : Transmit is completed
(TXEPT = 1)
1 : Transmit is completed
(TXEPT = 1)
U2RRM UART2 continuous
receive mode enable bit
0 : Continuous receive
mode disabled
1 : Continuous receive
mode enabled
Invalid
U2LCH Data logic select bit
0 : No reverse
1 : Reverse
0 : No reverse
1 : Reverse
U2ERE Error signal output
enable bit
Must be fixed to “0”
0 : Output disabled
1 : Output enabled
Figure 1.17.7. Serial I/O-related registers (4)
94
