Preliminary Information
MT9076
20.1.2 Master Control 2 (Page 02H) (T1)
Register
Names
Address
(A4A3A2A1A0)
10H (Table 37)
11H (Table 38)
12H
Configuration Control Word
LIU Tx Word
T1/E1, TxEN, LIUEn, ELOS, Tx8KEN, ADSEQ
CPL, TxLB2-0
Reserved
Set all bits to zero for normal operation.
13H (Table 39) Jitter Attenuator Control Word
JFC, JFD2-JFD0, JACL
14H
Reserved
Set all bits to zero for normal operation.
15H
Reserved
Set all bits to zero for normal operation.
16H (Table 40)
17H (Table 41)
18H (Table 42)
19H (Table 43)
1AH (Table 44)
1BH (Table 45)
1CH (Table 46)
1DH (Table 47)
1EH (Table 48)
1FH (Table 49)
Equalizer High Threshold
Equalizer Low Threshold
Serial Config. Word
HDLC0 Select
EHT7-0
ELT7-0
IMA, T1DM, G.802, 8Men, 8MTS1-0
En, FDLSEL, CH4-0
En, CH4-0
En, CH4-0
CP6-0
HDLC1 Select
HDLC2 Select
Custom Pulse Word 1
Custom Pulse Word 2
Custom Pulse Word 3
Custom Pulse Word 4
CP6-0
CP6-0
CP6-0
Table 36 - Master Control 2 (Page 02H) (T1)
69
