WS128K32-XXX
White Electronic Designs
PIN CONFIGURATION FOR WS128K32-XG4TX1
TOP VIEW
FIGꢀ 2
PIN DESCRIPTION
I/O0-31 Data Inputs/Outputs
A0-16
WE
Address Inputs
Write Enables
Chip Selects
Output Enable
Power Supply
Ground
CS1-4
OE
VCC
GND
NC
Not Connected
BLOCK DIAGRAM
Note 1: Package Not Recommended For New Design
FIGꢀ 3
PIN CONFIGURATION FOR WS128K32-XG2UX, WS128K32-XG2LX, WS128K32-XG1TX AND
WS128K32-XG1UX1
PIN DESCRIPTION
TOP VIEW
I/O0-31 Data Inputs/Outputs
A0-16
WE1-4
CS1-4
OE
Address Inputs
Write Enables
Chip Selects
Output Enable
Power Supply
Ground
VCC
GND
NC
Not Connected
BLOCK DIAGRAM
Note 1: Package Not Recommended For New Design
