M25PX16
Figure 1.
Logic diagram
VCC
Description
DQ0
C
S
W/V
PP
HOLD
M25PX16
DQ1
VSS
AI14228
Table 1.
Signal names
Function
Serial Clock
Serial Data input
Serial Data output
Chip Select
Write Protect/Enhanced Program supply voltage
Hold
Supply voltage
Ground
Input
I/O
(1)
I/O
(2)
Input
Input
Input
Direction
Signal name
C
DQ0
DQ1
S
W/V
PP
HOLD
V
CC
V
SS
1. Serves as an output during Dual Output Fast Read (DOFR) instructions.
2. Serves as an input during Dual Input Fast Program (DIFP) instructions.
Figure 2.
VFQFPN and SO8 connections
M25PX16
S 1
DQ1 2
W/V
PP
3
VSS 4
8
7
6
5
VCC
HOLD
C
DQ0
AI13720b
1. There is an exposed central pad on the underside of the VFQFPN package. This is pulled, internally, to
V
SS
, and must not be allowed to be connected to any other voltage or signal line on the PCB.
2. See
Package mechanical
7/65
