1 Mbit / 2 Mbit / 4 Mbit Multi-Purpose Flash
SST39SF010A / SST39SF020A / SST39SF040
Data Sheet
Packaging Diagrams
TOP VIEW
SIDE VIEW
BOTTOM VIEW
.495
.485
.453
.447
.112
.106
Optional
Pin #1
Identifier
.048
.042
.029
.023
.040
.030
.020 R.
MAX.
x 30°
R.
2
1
32
.042
.048
.021
.013
.400
BSC
.530
.490
.595 .553
.585 .547
.032
.026
.050
BSC
.015 Min.
.095
.075
.050
BSC
.032
.026
.140
.125
Note: 1. Complies with JEDEC publication 95 MS-016 AE dimensions, although some dimensions may be more stringent.
2. All linear dimensions are in inches (max/min).
3. Dimensions do not include mold flash. Maximum allowable mold flash is .008 inches.
4. Coplanarity: 4 mils.
32-plcc-NH-3
Figure 20:32-lead Plastic Lead Chip Carrier (PLCC)
SST Package Code: NH
©2013 Silicon Storage Technology, Inc.
DS25022B
04/13
25
