PIC17C75X
TABLE 10-7: PORTD FUNCTIONS
Name
Bit
Buffer Type
Function
RD0/AD8
RD1/AD9
RD2/AD10
RD3/AD11
RD4/AD12
RD5/AD13
RD6/AD14
RD7/AD15
bit0
bit1
bit2
bit3
bit4
bit5
bit6
bit7
TTL
TTL
TTL
TTL
TTL
TTL
TTL
TTL
Input/Output or system bus address/data pin.
Input/Output or system bus address/data pin.
Input/Output or system bus address/data pin.
Input/Output or system bus address/data pin.
Input/Output or system bus address/data pin.
Input/Output or system bus address/data pin.
Input/Output or system bus address/data pin.
Input/Output or system bus address/data pin.
Legend: TTL = TTL input.
TABLE 10-8: REGISTERS/BITS ASSOCIATED WITH PORTD
Value on
POR,
BOR
Value on all
other resets
(Note1)
Address
Name
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
RD7/
AD15
RD6/
AD14
RD5/
AD13
RD4/
AD12
RD3/
AD11
RD2/
AD10
RD1/
AD9
RD0/
AD8
13h, Bank 1 PORTD
12h, Bank 1 DDRD
xxxx xxxx
1111 1111
uuuu uuuu
1111 1111
Data direction register for PORTD
Legend: x= unknown, u= unchanged.
Note 1: Other (non power-up) resets include: external reset through MCLR and the Watchdog Timer Reset.
