PIC17C75X
G.10 PIC16C9XX Family Of Devices
PIC16C923
PIC16C924
Clock
Maximum Frequency of Operation (MHz)
EPROM Program Memory
Data Memory (bytes)
8
8
4K
176
4K
176
Memory
Timer Module(s)
TMR0,
TMR1,
TMR2
TMR0,
TMR1,
TMR2
Capture/Compare/PWM Module(s)
Serial Port(s)
(SPI/I C, USART)
1
1
2
2
SPI/I C
SPI/I C
Peripherals
2
Parallel Slave Port
—
—
—
5
A/D Converter (8-bit) Channels
LCD Module
4 Com,
32 Seg
4 Com,
32 Seg
Interrupt Sources
I/O Pins
8
9
25
25
Input Pins
27
27
Voltage Range (Volts)
In-Circuit Serial Programming
Brown-out Reset
Packages
3.0-6.0
Yes
—
3.0-6.0
Yes
—
Features
(1)
(1)
64-pin SDIP
TQFP;
,
64-pin SDIP
TQFP;
,
68-pin PLCC,
Die
68-pin PLCC,
Die
All PIC16/17 Family devices have Power-on Reset, selectable Watchdog Timer, selectable code protect and high I/O current capa-
bility. All PIC16C9XX Family devices use serial programming with clock pin RB6 and data pin RB7.
