PIC16F913/914/916/917/946
21.0 PACKAGING INFORMATION
21.1 Package Marking Information
28-Lead SPDIP
Example
Example
PIC16F913
XXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXX
e
3
-I/SP
YYWWNNN
0710017
40-Lead PDIP
XXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXX
YYWWNNN
PIC16F914
-I/P
e
3
0710017
Example
-I/ML
28-Lead QFN
16F916
XXXXXXXX
XXXXXXXX
YYWWNNN
e
3
0710017
Legend: XX...X Customer-specific information
Y
Year code (last digit of calendar year)
YY
WW
NNN
Year code (last 2 digits of calendar year)
Week code (week of January 1 is week ‘01’)
Alphanumeric traceability code
e
3
Pb-free JEDEC designator for Matte Tin (Sn)
*
This package is Pb-free. The Pb-free JEDEC designator (
can be found on the outer packaging for this package.
)
e3
Note: In the event the full Microchip part number cannot be marked on one line, it will
be carried over to the next line, thus limiting the number of available
characters for customer-specific information.
*
Standard PIC® device marking consists of Microchip part number, year code, week code and traceability
code. For PIC® device marking beyond this, certain price adders apply. Please check with your
Microchip Sales Office. For QTP devices, any special marking adders are included in QTP price.
© 2007 Microchip Technology Inc.
DS41250F-page 305
