PIC16F913/914/916/917/946
TABLE 19-13: PIC16F913/914/916/917/946 PLVD CHARACTERISTICS:
Standard Operating Conditions (unless otherwise stated)
DC CHARACTERISTICS
Operating Temperature
Operating Voltage
-40°C ≤ TA ≤ +125°C
VDD Range 2.0V-5.5V
Max.
(85°C)
Max.
(125°C)
Sym.
Characteristic
Min.
Typ†
Units
Conditions
VPLVD
PLVD
Voltage
LVDL<2:0> = 001
LVDL<2:0> = 010
LVDL<2:0> = 011
LVDL<2:0> = 100
LVDL<2:0> = 101
LVDL<2:0> = 110
LVDL<2:0> = 111
1.900
2.000
2.100
2.200
3.825
4.025
4.425
—
2.0
2.1
2.2
2.3
4.0
4.2
4.5
2.100
2.200
2.300
2.400
4.175
4.375
4.675
—
2.125
2.225
2.325
2.425
4.200
4.400
4.700
—
V
V
V
V
V
V
V
*TPLVDS PLVD Settling time
50
25
μs
VDD = 5.0V
VDD = 3.0V
*
These parameters are characterized but not tested
†
Data in “Typ” column is at 5.0V, 25°C unless otherwise stated. These parameters are for design guidance
only and are not tested.
© 2007 Microchip Technology Inc.
DS41250F-page 277
