PIC16C55X(A)
PIC16C55X(A) Product Identification System
To order or to obtain information, e.g., on pricing or delivery, please use the listed part numbers, and refer to the factory or the listed
sales offices.
PART NO. -XX X /XX XXX
Pattern:
3-Digit Pattern Code for QTP (blank otherwise)
Package:
P
=
=
=
=
PDIP
SO
SS
JW*
SOIC (Gull Wing, 300 mil body)
SSOP (209 mil)
Examples:
Windowed CERDIP
f) PIC16C554A - 04/P 301 =
Commercial temp., PDIP pack-
age, 4 MHz, normal VDD limits,
QTP pattern #301.
g) PIC16LC558- 04I/SO =
Industrial temp., SOIC pack-
age, 200kHz, extended VDD
limits.
Temperature
Range:
-
=
=
=
0˚C to +70˚C
I
–40˚C to +85˚C
–40˚C to +125˚C
E
Frequency
Range:
04
04
20
=
=
=
200kHz (LP osc)
4 MHz (XT and RC osc)
20 MHz (HS osc)
Device:
PIC16C55X :VDD range 3.0V to 5.5V
PIC16C55XT:VDD range 3.0V to 5.5V (Tape and Reel)
PIC16C55XA: VDD range 3.0V to 5.5V
PIC16C55XAT: VDD range 3.0V to 5.5V (Tape and Reel)
PIC16LC55X:VDD range 2.5V to 5.5V
PIC16LC55XT:VDD range 2.5V to 5.5V (Tape and Reel)
* JW Devices are UV erasable and can be programmed to any device configuration. JW Devices meet the electrical requirement of
each oscillator type (including LC devices).
Sales and Support
Products supported by a preliminary Data Sheet may possibly have an errata sheet describing minor operational differences and
recommended workarounds. To determine if an errata sheet exists for a particular device, please contact one of the following:
1. Your local Microchip sales office (see below)
2. The Microchip Corporate Literature Center U.S. FAX: (602) 786-7277
3. The Microchip’s Bulletin Board, via your local CompuServe number (CompuServe membership NOT required).
Please specify which device, revision of silicon and Data Sheet (include Literature #) you are using.
For latest version information and upgrade kits for Microchip Development Tools, please call 1-800-755-2345 or 1-602-786-7302.
1997 Microchip Technology Inc.
Preliminary
DS40143B-page 95
