PIC16C55X(A)
10.3
DC CHARACTERISTICS:
PIC16C55X(A) (Commercial, Industrial, Extended)
PIC16LC55X (Commercial, Industrial, Extended) (Cont.)
Standard Operating Conditions (unless otherwise stated)
Operating temperature –40˚C ≤ TA ≤ +85˚C for industrial and
0˚C ≤ TA ≤ +70˚C for commercial and
–40˚C ≤ TA ≤ +125˚C for automotive
Operating voltage VDD range as described in DC spec Table 10-1
Sym
Param.
No.
Characteristic
Min Typ†
Max
Unit
Conditions
Capacitive Loading Specs
on Output Pins
OSC2 pin
COSC2
Cio
D100
D101
15
50
pF In XT, HS and LP modes when external
clock used to drive OSC1.
All I/O pins/OSC2 (in RC
mode)
pF
*
These parameters are characterized but not tested.
†
Data in “Typ” column is at 5.0V, 25°C unless otherwise stated. These parameters are for design guidance
only and are not tested.
Note 1: In RC oscillator configuration, the OSC1 pin is a Schmitt Trigger input. It is not recommended that the
PIC16C55X(A) be driven with external clock in RC mode.
2: The leakage current on the MCLR pin is strongly dependent on applied voltage level. The specified levels
represent normal operating conditions. Higher leakage current may be measured at different input voltages.
3: Negative current is defined as coming out of the pin.
DS40143B-page 72
Preliminary
1997 Microchip Technology Inc.
