PIC16F872
15.0 DC AND AC
CHARACTERISTICS GRAPHS
AND TABLES
The graphs and tables provided in this section are for
design guidance and are not tested.
In some graphs or tables, the data presented are out-
side specified operating range (i.e., outside specified
VDD range). This is for information only and devices
are ensured to operate properly only within the speci-
fied range.
The data presented in this section is a statistical sum-
mary of data collected on units from different lots over
a period of time and matrix samples. ’Typical’ repre-
sents the mean of the distribution at 25°C. ’Max’ or ’min’
represents (mean + 3σ) or (mean - 3σ) respectively,
where σ is standard deviation, over the whole temper-
ature range.
Graphs and Tables not available at this time.
