PIC16F/LF1946/47
Pin Diagram – 64-Pin TQFP/QFN (PIC16F/LF1946/47)
64-pin TQFP, QFN
64
63 62 61 60 59 58 57 56 55 54 53 52 51 50 49
VLCD2/P2C(1)/RE1
VLCD1/P2D(1)/RE0
SEG42/P3A/CCP3/RG0
RB0/INT/SRI/FLT0/SEG30
RB1/SEG8
RB2/SEG9
RB3/SEG10
RB4/SEG11
RB5/T1G/SEG29
RB6/ICSPCLK/ICDCLK/SEG38
VSS
RA6/OSC2/CLKOUT/SEG36
RA7/OSC1/CLKIN/SEG37
VDD
RB7/ICSPDAT/ICDDAT/SEG39
RC5/SDO1/SEG12
RC4/SDI1/SDA1/SEG16
RC3/SCK1/SCL1/SEG17
RC2/CCP1/P1A/SEG13
1
2
3
4
5
6
7
8
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
SEG43/C3OUT/CK2/TX2/CPS15/AN15/RG1
SEG44/C3IN+/DT2/RX2/CPS14/AN14/RG2
SEG45/P3D/CCP4/C3IN0-/CPS13/AN13/RG3
VPP/MCLR/RG5
PIC16F/LF1946/47
SEG26/P1D/CCP5/C3IN1-/CPS12/AN12/RG4
VSS
VDD
9
10
11
12
13
14
15
16
SEG25/SS1/C1IN3-/C2IN3-/C3IN3-/CPS5/AN5/RF7
SEG24/C1IN+/CPS11/AN11/RF6
SEG23/DACOUT/C1IN1-/C2IN1-/CPS10/AN10/RF5
SEG22/C2IN+/CPS9/AN9/RF4
SEG21/C1IN2-/C2IN2-/C3IN2-/CPS8/AN8/RF3
SEG20/SRQ/C1OUT/CPS7/AN7/RF2
17 18 19 20 21 22 23 24 25 26 27 28
29 3031 32
Note 1: Pin location selected by APFCON register setting.
2: QFN package orientation is the same. No leads are present on the QFN package.
