PIC16F/LF1946/47
For additional interface recommendations, refer to your
specific device programmer manual prior to PCB
design.
It is recommended that isolation devices be used to
separate the programming pins from other circuitry.
The type of isolation is highly dependent on the specific
application and may include devices such as resistors,
diodes, or even jumpers. See Figure 27-4 for more
information.
FIGURE 27-4:
TYPICAL CONNECTION FOR ICSP™ PROGRAMMING
External
Programming
Signals
Device to be
Programmed
VDD
VDD
VDD
VPP
VSS
MCLR/VPP
VSS
Data
ICSPDAT
ICSPCLK
Clock
*
*
*
To Normal Connections
Isolation devices (as required).
*
2010 Microchip Technology Inc.
Preliminary
DS41414A-page 365
