PIC12F683
8-Pin Flash-Based, 8-Bit CMOS Microcontrollers with
nanoWatt Technology
High-Performance RISC CPU
• Only 35 instructions to learn:
- All single-cycle instructions except branches
• Operating speed:
- DC – 20 MHz oscillator/clock input
- DC – 200 ns instruction cycle
• Interrupt capability
• 8-level deep hardware stack
• Direct, Indirect and Relative Addressing modes
Low-Power Features
• Standby Current:
- 1 nA @ 2.0V, typical
• Operating Current:
- 8.5
µA
@ 32 kHz, 2.0V, typical
- 100
µA
@ 1 MHz, 2.0V, typical
• Watchdog Timer Current:
- 1
µA
@ 2.0V, typical
Peripheral Features
Special Microcontroller Features
• Precision Internal Oscillator:
- Factory calibrated to ±1%
- Software selectable frequency range of
8 MHz to 31 kHz
- Two-speed Start-up mode
- Crystal fail detect for critical applications
- Clock mode switching during operation for
power savings
• Power-saving Sleep mode
• Wide operating voltage range. (2.0V-5.5V)
• Industrial and Extended temperature range
• Power-on Reset (POR)
• Power-up Timer (PWRT) and Oscillator Start-up
Timer (OST)
• Multiplexed Master Clear with pull-up/input pin
• Programmable code protection
• High Endurance Flash/EEPROM cell:
- 100,000 write Flash endurance
- 1,000,000 write EEPROM endurance
- Flash/Data EEPROM Retention: > 40 years
• 6 I/O pins with individual direction control:
- High current source/sink for direct LED drive
- Interrupt-on-pin change
- Individually programmable weak pull-ups
- Ultra Low-Power Wake-up on GP0
• Analog comparator module with:
- One analog comparator
- Programmable on-chip voltage reference
(CV
REF
) module (% of V
DD
)
- Comparator inputs and output externally
accessible
• A/D Converter:
- 10-bit resolution and 4 channels
• Timer0: 8-bit timer/counter with 8-bit
programmable prescaler
• Enhanced Timer1:
- 16-bit timer/counter with prescaler
- External Gate Input mode
- Option to use OSC1 and OSC2 in LP mode as
Timer1 oscillator if INTOSC mode selected
• Timer2: 8-bit timer/counter with 8-bit period
register, prescaler and postscaler
• Capture, Compare, PWM module:
- 16-bit Capture, max resolution 12.5 ns
- Compare, max resolution 200 ns
- 10-bit PWM, max frequency 20 kHz
• In-Circuit Serial Programming™ (ICSP™) via
two pins
Timers
8/16-bit
2/1
Program Memory
Device
Flash (words)
PIC12F683
2048
Data Memory
I/O
SRAM (bytes)
128
EEPROM (bytes)
256
6
4
1
10-bit A/D (ch) Comparators
2004 Microchip Technology Inc.
Preliminary
DS41211B-page 1
