MCP201
4.0
4.1
PACKAGING INFORMATION
Package Marking Information
8-Lead DFN-S
Example:
XXXXXXXX
XXXXXXXX
MCP201
E/MF
e
3
YYWW
NNN
0715
256
8-Lead PDIP (300 mil)
Example:
MCP201
XXXXXXXX
XXXXXNNN
e
3
E/P256
0715
YYWW
8-Lead SOIC (150 mil)
Example:
XXXXXXXX
XXXXYYWW
e
3
MCP201
E/SN0715
NNN
256
Legend: XX...X Customer-specific information
Y
YY
WW
NNN
Year code (last digit of calendar year)
Year code (last 2 digits of calendar year)
Week code (week of January 1 is week ‘01’)
Alphanumeric traceability code
e
3
Pb-free JEDEC designator for Matte Tin (Sn)
*
This package is Pb-free. The Pb-free JEDEC designator (
can be found on the outer packaging for this package.
)
e3
Note: In the event the full Microchip part number cannot be marked on one line, it will
be carried over to the next line, thus limiting the number of available
characters for customer-specific information.
© 2007 Microchip Technology Inc.
DS21730F-page 31
