MCP1401/02
DC CHARACTERISTICS (OVER OPERATING TEMPERATURE RANGE)
Electrical Specifications: Unless otherwise indicated, operating temperature range with 4.5V ≤ VDD ≤ 18V.
Parameters
Sym
Min
Typ
Max
Units
Conditions
Input
Logic ‘1’, High Input Voltage VIH
2.4
—
—
—
—
—
—
0.8
V
V
Logic ‘0’, Low Input Voltage
Input Current
VIL
IIN
–10
-5
+10
µA
V
0V ≤ VIN ≤ VDD
Input Voltage
VIN
VDD+0.3
Output
High Output Voltage
Low Output Voltage
Output Resistance, High
Output Resistance, Low
Switching Time (Note 1)
Rise Time
VOH VDD – 0.025
—
—
12
10
—
0.025
18
V
V
Ω
Ω
DC TEST
VOL
ROH
ROL
—
—
—
DC TEST
IOUT = 10 mA, VDD = 18V
IOUT = 10 mA, VDD = 18V
16
tR
tF
—
—
20
18
30
28
ns
ns
Figure 4-1, Figure 4-2
CL = 470 pF
Fall Time
Figure 4-1, Figure 4-2
CL = 470 pF
Delay Time
tD1
tD2
—
—
40
40
51
51
ns
ns
Figure 4-1, Figure 4-2
Figure 4-1, Figure 4-2
Delay Time
Power Supply
Supply Voltage
Power Supply Current
VDD
IS
4.5
—
18.0
V
—
—
0.90
0.11
1.10
0.20
mA
mA
VIN = 3V
VIN = 0V
Note 1: Switching times ensured by design.
2: Tested during characterization, not production tested.
TEMPERATURE CHARACTERISTICS
Electrical Specifications: Unless otherwise noted, all parameters apply with 4.5V ≤ VDD ≤ 18V.
Parameters
Sym
Min
Typ
Max
Units
Conditions
Temperature Ranges
Specified Temperature Range
Maximum Junction Temperature
Storage Temperature Range
Package Thermal Resistances
Thermal Resistance, 5L-SOT23
TA
TJ
TA
–40
—
—
—
—
+125
+150
+150
°C
°C
°C
–65
θJA
—
256
—
°C/W
DS22052A-page 4
