25AA512
4.0
4.1
PACKAGING INFORMATION
Package Marking Information
8-Lead DFN
Example:
XXXXXXX
T/XXXXX
YYWW
25AA512
I/MF
0728
1L7
e
3
NNN
Example:
25AA512
8-Lead PDIP
XXXXXXXX
T/XXXNNN
I/P
1L7
e
3
0728
YYWW
Example:
8-Lead SOIC
25AA512I
XXXXXXXT
e
3
SN 0728
XXXXYYWW
1L7
NNN
Example:
25AA512
8-Lead SOIJ
XXXXXXXX
T/XXXXXX
YYWWNNN
I/SM
07281L7
e3
Legend: XX...X Part number or part number code
T
Temperature (I)
Y
Year code (last digit of calendar year)
Year code (last 2 digits of calendar year)
Week code (week of January 1 is week ‘01’)
Alphanumeric traceability code (2 characters for small packages)
Pb-free JEDEC designator for Matte Tin (Sn)
YY
WW
NNN
e
3
Note:
For very small packages with no room for the Pb-free JEDEC designator
, the marking will only appear on the outer carton or reel label.
e
3
Note: In the event the full Microchip part number cannot be marked on one line, it will
be carried over to the next line, thus limiting the number of available
characters for customer-specific information.
2010 Microchip Technology Inc.
DS22021F-page 21
