DC Electrical Characteristics(6)
VDD = 48V, VEE = 0V, TA = 25°C, unless otherwise noted. Bold indicates specifications apply over the full operating temperature
range of –40°C to 85°C.
Symbol
Parameter
Condition
Min
0.5
Typ
Max
0.8
Units
VTHRESH(PG2) PGTIMER Threshold Voltage for
PWRGD2 and /PWRGD2
0.63
V
VTHRESH(PG3) PGTIMER Threshold Voltage for
PWRGD3 and /PWRGD3
1.00
1.15
1.30
V
RPGTIMER
VOVH
PGTIMER Discharge Resistance Voltage on PGTIMER = 0.5 V
250
500
750
Ω
OV Pin High Threshold Voltage
(MIC2589 and MIC2589R)
Low-to-High transition
1.198
1.223
1.247
V
VOVL
OV Pin Low threshold Voltage
(MIC2589 and MIC2589R)
High-to-Low transition
1.165
1.203
20
1.232
V
mV
V
VOVHYS
VUVL
OV Pin Hysteresis
(MIC2589 and MIC2589R)
UV Pin Low threshold Voltage
(MIC2589 and MIC2589R)
High-to-Low transition
Low-to-High transition
1.198
1.213
1.223
1.243
20
1.247
1.272
VUVH
UV Pin High Threshold Voltage
(MIC2589 and MIC2589R)
V
VUVHYS
VONH
UV Pin Hysteresis
(MIC2589 and MIC2589R)
mV
V
ON Pin High Threshold Voltage
(MIC2595 and MIC2595R)
Low-to-High transition
High-to-Low transition
VINPUT = 1.25V
1.198
1.198
1.223
1.223
1.247
1.247
0.5
VOFFL
ICNTRL
VPGTH
VOLPG
OFF Pin Low Threshold Voltage
(MIC2595 and MIC2595R)
V
Input Current (OV, UV, ON, OFF
Pins)
µA
V
Power-Good Threshold
High-to-Low Transition
1.1
1.26
1.40
0.8
(VDRAIN – VEE
)
PWRGD Output Voltage
(relative to voltage at the DRAIN
pin)
0 ≤ IPG ≤ 1mA
MIC25XX-1
-0.25
-0.25
V
(VDRAIN – VEE) > VPGTH
MIC25XX-2
(VDRAIN – VEE) < VPGTH
0.8
V
VOLPG – VDRAIN
ILKG(PG)
Note:
PWRGD Output Leakage
Current
VPWRGD = VDD = 80 V
1
µA
6. Specification for packaged product only.
