MX29LV640BT/BB
Sector Sector Sector Address
Sector Size
(Kbytes/Kwords)
64/32
(x8)
(x16)
Group
37
A21-A12
Address Range
Address Range
SA119 1110000xxx
SA120 1110001xxx
SA121 1110010xxx
SA122 1110011xxx
SA123 1110100xxx
SA124 1110101xxx
SA125 1110110xxx
SA126 1110111xxx
SA127 1111000xxx
SA128 1111001xxx
SA129 1111010xxx
SA130 1111011xxx
SA131 1111100xxx
SA132 1111101xxx
SA133 1111110xxx
SA134 1111111xxx
700000h-70FFFFh
710000h-71FFFFh
720000h-72FFFFh
730000h-73FFFFh
740000h-74FFFFh
750000h-75FFFFh
760000h-76FFFFh
770000h-77FFFFh
780000h-78FFFFh
790000h-79FFFFh
7A0000h-7AFFFFh
7B0000h-7BFFFFh
7C0000h-7CFFFFh
7D0000h-7DFFFFh
7E0000h-7EFFFFh
7F0000h-7FFFFFh
380000h-387FFFh
388000h-38FFFFh
390000h-397FFFh
398000h-39FFFFh
3A0000h-3A7FFFh
3A8000h-3AFFFFh
3B0000h-3B7FFFh
3B8000h-3BFFFFh
3C0000h-3C7FFFh
3C8000h-3CFFFFh
3D0000h-3D7FFFh
3D8000h-3DFFFFh
3E0000h-3E7FFFh
3E8000h-3EFFFFh
3F0000h-3F7FFFh
3F8000h-3FFFFFh
37
64/32
37
64/32
37
64/32
38
64/32
38
64/32
38
64/32
38
64/32
39
64/32
39
64/32
39
64/32
39
64/32
40
64/32
40
64/32
40
64/32
40
64/32
Note:The address range is A20:A-1 in byte mode (BYTE#=VIL) or A20:A0 in word mode (BYTE#=VIH)
Bottom Boot Security Sector Addresses
Sector Address
A21~A12
Sector Size
(bytes/words)
256/128
(x8)
(x16)
Address Range
000000h-0000FFh
Address Range
000000-00007Fh
0000000000
