MX25L8005
RECOMMENDED OPERATING CONDITIONS
AtDevicePower-Up
AC timing illustrated in Figure A is recommended for the supply voltages and the control signals at device power-up. If
the timing in the figure is ignored, the device may not operate correctly.
VCC(min)
VCC
GND
tSHSL
tVR
CS#
tCHSL
tSLCH
tCHSH
tSHCH
SCLK
tDVCH
tCHCL
tCHDX
tCLCH
MSB IN
LSB IN
SI
High Impedance
SO
Figure A. AC Timing at Device Power-Up
Symbol
Parameter
VCC Rise Time
Notes
Min.
Max.
500000
Unit
tVR
1
0.5
us/V
Notes :
1. Sampled, not 100% tested.
2. For AC spec tCHSL, tSLCH, tDVCH, tCHDX, tSHSL, tCHSH, tSHCH, tCHCL, tCLCH in the figure, please refer to "AC
CHARACTERISTICS"table.
P/N:PM1237
REV. 2.2, OCT. 23, 2008
33
