MX29F080
ABSOLUTE MAXIMUM RATINGS
RATING
VALUE
NOTICE:
Ambient Operating Temperature 0oC to 70oC
Stresses greater than those listed under ABSOLUTE MAXIMUM
RATINGS may cause permanent damage to the device. This is
a stress rating only and functional operational sections of this
specification is not implied. Exposure to absolute maximum rating
conditions for extended period may affect reliability.
Storage Temperature
Applied Input Voltage
Applied Output Voltage
VCC to Ground Potential
A9 & OE
-65oC to 125oC
-0.5V to 7.0V
-0.5V to 7.0V
-0.5V to 7.0V
-0.5V to 13.5V
NOTICE:
Specifications contained within the following tables are subject to
change.
READ TIMING WAVEFORMS
VIH
ADD Valid
Addresses
VIL
tCE
VIH
CE
VIL
VIH
WE
tDF
VIL
tOE
VIH
OE
tACC
VIL
tOH
HIGH Z
HIGH Z
VOH
VOL
Outputs
DATA Valid
COMMAND PROGRAMMING/DATA PROGRAMMING/ERASE OPERATION
DC CHARACTERISTICS (TA = 0oC to 70oC,VCC = 5V±10%)
SYMBOL
PARAMETER
MIN.
TYP
MAX.
30
UNIT
mA
mA
mA
mA
mA
CONDITIONS
ICC1 (Read)
ICC2
Operating VCC Current
IOUT=0mA, f=1MHz
IOUT=0mA, F=10MHz
In Programming
50
ICC3 (Program)
ICC4 (Erase)
ICCES
50
50
In Erase
VCC Erase Suspend Current
2
CE=VIH, Erase Suspended
NOTES:
1. VILmin.=-0.6Vforpulsewidthisequaltoorlessthan20ns.
2. If VIH is over the specified maximum value, programming
operation cannot be guranteed.
device is read during erase suspend mode, current draw
is the sum of ICCES and ICC1 or ICC2.
4. All current are in RMS unless otherwise noted.
3. ICCES is specified with the device de-selected. If the
P/N:PM0579
REV. 1.6, NOV. 21, 2002
15
