MAX11329–MAX11332
3Msps, 12-/10-Bit, 8-/16-Channel ADCs with
Post-Mux External Signal Conditioning Access
Full-Linear Bandwidth
Full-linear bandwidth is the frequency at which the
Chip Information
signal-to-noise plus distortion (SINAD) is more than 70dB
(MAX11331/MAX11332).
PROCESS: BiCMOS
Intermodulation Distortion
Any device with nonlinearities creates distortion products
when two sine waves at two different frequencies (f1 and
f2) are input into the device. Intermodulation distortion
(IMD) is the total power of the IM2 to IM5 intermodulation
products to the Nyquist frequency relative to the total
input power of the two input tones, f1 and f2. The indi-
vidual input tone levels are at -6dBFS.
Ordering Information
PART
PIN-PACKAGE
32 TQFN-EP**
32 TQFN-EP**
32 TQFN-EP**
32 TQFN-EP**
BITS
10
SPEED (Msps)
NO. OF CHANNELS
MAX11329ATJ+
MAX11330ATJ+*
MAX11331ATJ+
MAX11332ATJ+*
3
3
3
3
16
8
10
12
16
8
12
Note: All devices are specified over the -40°C to +125°C temperature range.
+Denotes a lead(Pb)-free/RoHS-compliant package.
*Future product—contact factory for availability.
**EP = Exposed pad.
Package Information
For the latest package outline information and land patterns
(footprints), go to www.maxim-ic.com/packages. Note that a
“+”, “#”, or “-” in the package code indicates RoHS status only.
Package drawings may show a different suffix character, but
the drawing pertains to the package regardless of RoHS status.
PACKAGE
TYPE
PACKAGE OUTLINE
LAND
PATTERN NO.
CODE
NO.
32 TQFN-EP
T3255+5
21-0140
90-0013
