AMPLIMITE Subminiature D Connectors
AMPLIMITE .050 Series Panel Mount Plug Assemblies
With Rails, Latch Blocks, Series III
Plug
C
.050
[1.27]
Recessed Cavity
Identification
Typ.
.406
[10.31]
2-56 UNC
2 Plc.
Materials:
Housing and Termination Covers—
Thermoplastic, 94V-0 rated, black
E
Bracket—Zinc, plated nickel over
.004
0.10]
F
[
copper
Mating Face
.002
0.05
.217
[5.51
.001
0.03
Contacts—Phosphor bronze, duplex
plated .000030 [0.00076] min. gold on
mating end, bright tin in termination
area, all nickel underplated
.024
[0.61
Typ.
]
]
Recommended wire size—
28 AWG [0.08-0.09mm2] or
30 AWG [0.05mm2], solid or
7 strand, with a .029-.036
[0.74-0.89] insulation diameter or
.050 [1.27] centerline, 28 AWG
[0.08-0.09mm2]stranded, PVC, flat
ribbon cable.
.598
[15.19]
Ref.
.002
0.05
.154
[3.91
]
.007
0.18]
D
[
Technical Documents:
Product Specifications—108-1228
Application Specifications—
114-40029
Dimensions
No. of
Positions
Part
Numbers
Note: Extra pin contact protection is provided
by rails, which facilitate a straight-out, unmat-
ing motion. A side-to-side rocking motion
should not be used to disengage the connector
system.
C
D
E
F
1.830
1.629
2.065
1.665
50
68
5-749878-5
46.48
41.38
52.45
42.29
2.280
57.91
2.079
52.81
2.515
63.88
2.115
53.72
5-749878-7
5-749878-9
3.080
78.23
2.879
73.13
3.315
84.20
2.915
74.04
100
Note: All part numbers are RoHS compliant.
23
Catalog 82068
Revised 1-08
Dimensions are in inches and
Dimensions are shown for
