AMPLIMITE Subminiature D Connectors
AMPLIMITE .050 Series Shielded Enclosure Kits,
With Male Jackscrews, Series III
68-Position
Material and Finish:
Backshells—Zinc
Boot—PVC, black
Jackscrews—Stainless steel and PVC,
black
Staple—Carbon steel, plated tin over
nickel
Screws—Stainless steel, #2-56 threads
Technical Documents:
Product Specifications—108-1228
Application Specifications—
114-40029
.550
[13.97]
Max. Dia.
Cable Supplied
by Customer
1.887
[47.93]
Connector
(Must be
Purchased
Separately)
2.645
[67.18]
.660
[16.76]
.520
[13.21]
No. of
Pos.
Part Number
Male 2-56 Jackscrews
Part Number
Male 4-40 Jackscrews
68
5750752-1
5750752-2
Notes: 1. Each enclosure kit contains two backshells, one boot, two jackscrews,
one staple and two screws. All are packaged unassembled.
2. For staple insertion tooling see page 29.
3. Meets SCSI-3 standards.
Note: All part numbers are RoHS compliant.
20
Catalog 82068
Revised 1-08
Dimensions are in inches and
Dimensions are shown for
USA: 1-800-522-6752
South America: 55-11-2103-6000
Hong Kong: 852-2735-1628
Japan: 81-44-844-8013
millimeters unless otherwise
specified. Values in brackets
are metric equivalents.
reference purposes only.
Specifications subject
to change.
