NOTE: All part numbers
are RoHS Compliant
AMP M Series
Pin and Socket Connectors
Standard Housings (Continued)
160 CF Position
(with Center Fastener)
1.867
[47.42]
1.174
.915
[23.24]
.365
[29.82]
1.826±.010
[46.38±0.25
]
4.156
[105.56]
Ref.
.500
[12.70]
[9.27]
Typ.
2.795
.125
[3.18]
R. Typ.
[70.99]
.165
[4.19]
Ref.
2.374±.010
2.374
[60.30]
[60.30±0.25
Typ.
]
2.750±.010
[69.85±0.25
]
2.095
[53.21]
.010
.155
[0.25]
Dia.
[3.94]
.012
[0.31]
Typ.
(4 Holes)
Plug Housing
Phenolic Part No. 202799-2
Recommended Panel Cutout
Diallyl Phthalate Part No. 202799-1
1.826±.010
[46.38±0.25
]
2.750±.010
[69.85±0.25
2.374±.010
[60.30±0.25
Typ.
]
]
.365
[9.27]
Typ.
.915
[23.24]
Receptacle Housing
Phenolic Part No. 202800-2
Diallyl Phthalate Part No. 202800-1
Notes: 1. All housings accept Type II, Type III+, and Subminiature COAXICON contacts.
2. Pins and/or sockets may be used in any housing.
3. Dimensions are .005 [0.127].
4. Housing cavity identification are mirror image.
51
Catalog 82003
Revised 06-08
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets are
equivalent U.S. Customary Units.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
