NOTE: All part numbers
are RoHS Compliant
AMP M Series
Pin and Socket Connectors
Standard Housings (Continued)
No. of
Pos.
Housing
Material
Plug
Dimension
A
Receptacle
Dimension
B
26, 34 and 36 Positions
(Continued)
Part Number
Part Number
1.312
33.32
1.322
33.58
1.312
33.32
1.322
33.58
Phenolic
201359-1
200512-2
26
Diallyl
Phthalate
Phenolic
201359-3
1-201357-1
213799-1 (Modified) 1.686
213800-1
213800-2 (Pins only)
200512-3
200838-2
213801-1 (Modified) 1.686
213802-1
—
Related Product Data
Dimensions—Page 46
34
36
Polyester
42.82
42.82
Diallyl
Phthalate
1.696
43.08
2.281
57.94
1.696
43.08
201357-3
203956-2
200838-3
—
Phenolic
—
Notes: 1. All housings accept Type II, Type III+, and Subminiature COAXICON contacts.
2. Pins and/or sockets may be used in any housing, except for 213800-2, which accepts only pin
contacts.
3. Dimensions are .005 [0.127], unless otherwise noted.
4. Housing cavity identification are mirror image.
.915
[23.24]
.440±.010
41 Position
.550
[13.97]
[11.18±0.25
]
.120
[3.05]
Dia.
.275
[6.99]
.016
[0.41]
R. Typ.
.133
2.322
[58.98]
[3.38]
.129
[3.28]
Dia.
2.312
[58.72]
2.687±.020
[68.25±0.51
2.200
[55.88]
]
.061
[1.55]
.130
[3.30]
Dia.
.240±.020
[6.10±0.51
]
.365
[9.27]
Recommended Panel Cutout
Plug Housing
Receptacle Housing
Phenolic Part No. 202135-2
Phenolic Part No. 201302-1
Diallyl Phthalate Part No. 202135-4
Diallyl Phthalate Part No. 201302-3
.915
[23.24]
50 Position
.790
[20.01]
.750±.010
.365
[9.27]
[19.05±0.25
]
.395
.161
[4.09]
.750±.010
[10.03]
[19.05±0.25
]
.128
[3.25]
.016
[0.41]
R. Typ.
.133
+.015
[3.38]
2.281
-.005
+0.38
.129
[3.28]
Dia.
2.281
[57.94]
[
]
57.94 -0.13
2.593±.020
[65.91±0.51
2.025
[51.44]
]
.130 [3.3] Dia.
.130
Dia.
or
[3.30]
.468
[11.89]
.218 [5.54] Dia.
is required when
jackscrews are
used.
(4 Holes)
Recommended Panel Cutout
Plug Housing
Phenolic Part No. 201358-1
Diallyl Phthalate Part No. 201358-3
Receptacle Housing
Phenolic Part No. 200277-2
Diallyl Phthalate Part No. 200277-4
47
Catalog 82003
Revised 06-08
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets are
equivalent U.S. Customary Units.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
