TANTALUM HERMETICALLY SEALED / AXIAL — MIL-C-39003
ORDERING INFORMATION (OBSOLETE*)
CSR XX B 565 K M
FAILURE RATE LEVEL
TYPE
Capacitors, Fixed, Solid Electrolyte, Tantalum
Established Reliability
IN % PER 1000 HOURS
GRADED
EXPONENTIAL
A — Not Applicable
B — 0.1%/k hrs.
C — 0.01%/k hrs.
M —
P — 0.1%/k hrs.
R — 0.01%/k hrs.
1%/k hrs.
STYLE
Tubular Case — Always Sleeved
09 — Miniature — T222
13 — Standard — T212
D — 0.001%/k hrs. S — 0.001%k hrs.
21 — Standard, low ESR — T262
23 — Extended Range — T242
33 — Extended Range, Low Leakage — T252
91 — Non-Polar — T213
CAPACITANCE
TOLERANCE
J — ± 5%
K — ± 10%
M — ± 20%
VOLTAGE
CAPACITANCE
Expressed in picofarads (1 microfarad = 1,000,000
picofarads). First two digits represent significant figures.
Last digit specifies the number of zeros to follow.
Examples
VDC Working
85°C
VDC Surge
Symbol
B
C
D
E
F
G
H
J
125°C
4
7
10
13
23
33
50
67
85°C
8
125°C
5
9
12
16
28
40
64
86
565 — 5,600,000 = 5.60 µF
564 — 560,000 = .56 µF
563 — 56,000 = .056 µF
6
10
15
20
35
50
75
100
13
20
26
46
65
98
130
This Military Part Numbering System is obsolete in accordance with the
*
current specifications. The correct current designation for a CSR part
number is the MIL Specification Number, followed by the Specification
(slash) Sheet Number and Dash Number (i.e. — MIL-C-39003/01-2270).
However, the part number breakdown shown above is still widely used
and is shown for reference.
MILITARY CAPACITOR APPROVED FAILURE RATE LEVELS AND MARKINGS PER
MIL-C-39003 FOR CSR09 (T222 A & B CASE SIZES ONLY), CSR13 (T212),
CSR21 (T262), CSR23 (T242) & CSR33 (T252) CAPACITORS
KEMET APPROVED FAILURE RATE LEVELS — MIL-C-39003/H (EXPONENTIAL)
KEMET
SERIES
APPROVED FAILURE
RATE LEVEL
KEMET
SERIES
APPROVED FAILURE
RATE LEVEL
STYLE
DESCRIPTION
STYLE
DESCRIPTION
CSR09 Polar-Subminiature
CSR13 Polar-Standard
MIL Range
T222
T212
S (0.001%/k hrs.)
S (0.001%/k hrs.)
CSR33 Polar-Extended Range
Low Leakage
T252
T213
S (0.001%/k hrs.)
S (0.001%/k hrs.)
CSR91 Non-Polar
CSR21 Polar-Standard Low ESR
MIL Range
T262
T242
S (0.001%/k hrs.)
S (0.001%/k hrs.)
CSR23 Polar-Extended Range
MILITARY MARKING
A CASE
C & D CASES
Military specification number
Military specification number
Specification sheet number, Military
dash number, and “J” for JAN
Positive terminal identifier and capacitance value
Capacitance tolerance and voltage
Source code
39003
01 - K
9002J
+933
M39003
01 - 8222J
Specification sheet number and trademark
Military dash number and “J” for JAN
Polarity, date code (1st digit indicates year and the next two
digits indicate the week)
+6.8 µF
10% 50V
31433
Lot symbol
XY
Date code, lot code, and trademark
9933 XY K
CSR91 (T213) CAPACITORS
A, B, C & D CASES
B CASE
Military specification number
Specification sheet number, Military dash
number, and “J” for JAN
Capacitance value
Capacitance tolerance and voltage rating
Date code, lot code, and source code
M39003
01 -
8006J
31433
+933 XY
Military specification number
Specification sheet number
Military dash number and “J” for JAN
Source code
Polarity, date code (1st digit indicates year and the next two
digits indicate the week), lot symbol
M39003
04 - 0980J
1 µF
10% 20VNP
9933 XY 31433
(See page 38 for CSS Marking)
