KEMET®
TANTALUM MOLDED / RADIAL
T330 SERIES - PRECISION MOLDED - RADIAL LEADS
B, C & D CASES (Cont’d)
MAX.
DISSIPATION
FACTOR
%@25°C,
120Hz
MAX.
DISSIPATION
FACTOR
%@25°C,
120Hz
CAPAC-
ITANCE
µF
D.C.
LEAKAGE
µA@25°C
CAPAC-
ITANCE
µF
D.C.
LEAKAGE
µA@25°C
CASE
SIZE
CASE
SIZE
KEMET PART NUMBER
KEMET PART NUMBER
25 VOLT RATING AT 85°C — 17 VOLT RATING AT 125°C
35 VOLT RATING AT 85°C — 23 VOLT RATING AT 125°C
2.7
3.3
3.9
4.7
B
B
B
B
T330B275(1)025AS
T330B335(1)025AS
T330B395(1)025AS
T330B475(1)025AS
1
1
1
1
6
6
6
6
6.8
8.2
10.0
C
C
C
T330C685(1)035AS
T330C825(1)035AS
T330C106(1)035AS
2
5
5
6
6
6
12.0
15.0
18.0
22.0
27.0
33.0
D
D
D
D
D
D
T330D126(1)035AS
T330D156(1)035AS
T330D186(1)035AS
T330D226(1)035AS
T330D276(1)035AS
T330D336(1)035AS
5
5
10
10
10
10
6
6
6
6
6
6
5.6
6.8
8.2
10.0
12.0
15.0
C
C
C
C
C
C
T330C565(1)025AS
T330C685(1)025AS
T330C825(1)025AS
T330C106(1)025AS
T330C126(1)025AS
T330C156(1)025AS
1
1
1
1
1
2
6
6
6
6
6
6
50 VOLT RATING AT 85°C—33 VOLT RATING AT 125°C
18.0
22.0
27.0
33.0
39.0
47.0
D
D
D
D
D
D
T330D186(1)025AS
T330D226(1)025AS
T330D276(1)025AS
T330D336(1)025AS
T330D396(1)025AS
T330D476(1)025AS
5
5
5
5
10
10
6
6
6
6
6
6
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
T330B104(1)050AS
T330B124(1)050AS
T330B154(1)050AS
T330B184(1)050AS
T330B224(1)050AS
T330B274(1)050AS
T330B334(1)050AS
T330B394(1)050AS
T330B474(1)050AS
T330B564(1)050AS
T330B684(1)050AS
T330B824(1)050AS
T330B105(1)050AS
T330B125(1)050AS
T330B155(1)050AS
T330B185(1)050AS
T330B225(1)050AS
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
35 VOLT RATING AT 85°C—23 VOLT RATING AT 125°C
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
T330B104(1)035AS
T330B124(1)035AS
T330B154(1)035AS
T330B184(1)035AS
T330B224(1)035AS
T330B274(1)035AS
T330B334(1)035AS
T330B394(1)035AS
T330B474(1)035AS
T330B564(1)035AS
T330B684(1)035AS
T330B824(1)035AS
T330B105(1)035AS
T330B125(1)035AS
T330B155(1)035AS
T330B185(1)035AS
T330B225(1)035AS
T330B275(1)035AS
T330B335(1)035AS
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
C
C
C
C
C
T330C275(1)050AS
T330C335(1)050AS
T330C395(1)050AS
T330C475(1)050AS
T330C565(1)050AS
1
2
5
5
5
6
6
6
6
6
6.8
8.2
10.0
12.0
15.0
18.0
D
D
D
D
D
D
T330D685(1)050AS
T330D825(1)050AS
T330D106(1)050AS
T330D126(1)050AS
T330D156(1)050AS
T330D186(1)050AS
5
5
5
5
10
10
6
6
6
6
6
6
3.9
4.7
5.6
C
C
C
T330C395(1)035AS
T330C475(1)035AS
T330C565(1)035AS
1
1
1
6
6
6
(1) To complete Part Number insert Capacitance Tolerance Symbol in the 9th character, M — ±20%, K — ±10%, J — ±5%.
Bold face lines indicate popular part types and values.
Higher voltage and better capacitance tolerance product may be substituted for an order within the same case size at KEMET’S option.
52
KEMET Electronics Corporation, P.O. Box 5928, Greenville, S.C. 29606 (864) 963-6300
