KEMET®
TANTALUM MOLDED / RADIAL
T330 SERIES - PRECISION MOLDED - RADIAL LEAD
CAPACITOR OUTLINE DRAWINGS
W
W
A CASE
B, C, & D CASES
.150±.005
.015±.005
(.38±.13)
H
H
(.38±.13)
(Stand Off)
(Stand Off)
E
E
.500±.125
(12.7±.3.18)
.500±.125
(12.7±.3.18)
.020±.001
(.51±.03)
.25±.001
(.64±.03)
Note:
S
S
.050R±.005
(1.27R±.13)
On the "B" case size the
stand off appears only
between the two leadss
T
T
DIMENSIONS — INCHES & (MILLIMETERS)
CASE
SIZE
H
W
T
E
S
CASE HEIGHT
CASE WIDTH
CASE THICKNESS
CASE TO WIRE
LEAD SPACING
A
B
C
D
.345 ± .008
(8.76 ± .203)
.230 ± .005
(5.84 ± .127)
.105 ± .005
(2.67 ± .127)
.050 ± .010
(1.27 ± .25)
.125 ± .005
(3.18 ± .127)
.225 ± .015
(5.71 ± 0.38)
.285 ± .015
(7.24 ± 0.38)
.170 ± .015
(4.32 ± 0.38)
.042 ± .010
(1.07 ± .25)
.200 ± .005
(5.08 ± .127)
.325 ± .015
(8.26 ± 0.38)
.325 ± .015
(8.26 ± 0.38)
.170 ± .015
(4.32 ± 0.38)
.062 ± .010
(1.57 ± 0.25)
.200 ± .005
(5.08 ± .127)
.375 ± .015
.600 ± .015
.195 ± .015
.200 ± .010
.200 ± .005
(9.53 ± 0.38)
(15.24 ± 0.38)
(4.95 ± 0.38)
(5.08 ± 0.25)
(5.08 ± .127)
ORDERING INFORMATION
T 330 B 104 M 035 A S*
TANTALUM
LEAD MATERIAL
S — Standard (Solder-Coated Nickel)
SERIES
Radial Lead
FAILURE RATE LEVEL
A — Not Applicable
Precision Molded Polar
Solid Tantalum
VOLTAGE RATING
CAP. TOLERANCE
CASE SIZE
A / B / C / D
M — ±20% — Std.
K — ±10% — Std.
J — ±5% — Available on
request
PICOFARAD CODE
First two digits are significant figures.
Third digit is the number of zeros following.
*Part Number Example: T330B104M035AS (14 digits – no spaces)
MARKING INFORMATION
Capacitance
Tolerance:
5% - J
10% - K
20% - Standard (no mark)
4.7K
25K
+
Polarity
KEMET Trademark
Voltage Rating
50
KEMET Electronics Corporation, P.O. Box 5928, Greenville, S.C. 29606 (864) 963-6300
