TANTALUM HERMETICALLY SEALED / AXIAL — MIL-C-39003
T216 (CSS13) & T256 (CSS33) SERIES
MIL-C-39003/10 ORDERING INFORMATION
M39003/10 — 3078S
Military Specification
Document Number
S — designates sleeved
U — designates unsleeved
Slash Sheet Number
MIL dash number signifies
capacitance, voltage and failure
rate (see ratings and part number
tables).
MARKING INFORMATION
A CASE
C & D CASE
Military specification number
39003
10 - K
3078S
+J910
M39003
10-2049SJ
Military specification number
Specification sheet number, military dash number
and “J” for Jan.
Positive terminal identifier and capacitance value
Capacitance tolerance and voltage rating
Source code
Specification sheet number and trademark
Military dash number and “S” for sleeved
Polarity, “J” for JAN date code (1st digit indicates year
and the next two digits indicate the week
Lot, unique lot code
+6.8 µF
10% 35V
31433
XYA
9910 NAB K
Date code, lot code, unique lot code, and trademark
NOTE: Marking will include S or U after the MIL dash number, a
third letter following lot symbol or lot code designates a unique lot
identifier, and a black band on negative end of case.
B CASE
Military specification number
Specification sheet number
Military dash number and “J” for JAN
Source code
M39003
10 -
3082SJ
31433
+910
Polarity, date code (1st digit indicates year and the next two digits indicate the week
Lot code, unique lot code and trademark.
NABK
Black band on negative end.
T216/(CSS13)
RATINGS & PART NUMBER REFERENCE
KEMET T216
MIL-C-39003 (CSS13) CAPACITORS
DASH NUMBER REFERENCE
FAILURE RATE LEVEL (%/1000 HRS)
MIL-C-39003/10 GRADED
DC LEAKAGE
MAX. DISSIPATION FACTOR
KEMET EQUIVALENT
PART NUMBER FOR
CSS13 CAPACITORS
MAX. ESR
Ω @ 25°C
100kHz
CAPACITANCE
µF
CASE
SIZE
µA @ +25°
MAX.
µA @ +85°
MAX.
µA @ +125°
MAX.
% @ -55°C
+25°C MAX.
% @ -85°C
+125°C MAX.
B
C
(0.1)
(0.01)
6 VOLT RATING AT 85°C
5.6
6.8
A
A
T216A565K006CS
T216A685K006CS
.3
.3
6.0
6.0
7.5
7..5
4
6
4
6
.90
.80
3001(1)
3002(1)
47.0
56.0
B
B
T216B476K006CS
T216B566K006CS
1.5
1.5
24.0
24.0
30.0
30.0
6
6
6
6
.24
.24
3003(1)
3004(1)
150.0
180.0
C
C
T216C157K006CS
T216C187K006CS
4.5
5.5
90.0
110.0
113.0
138.0
8
8
8
8
.09
.08
3005(1)
3006(1)
270.0
330.0
D
D
T216D277K006CS
T216D337K006CS
6.5
7.5
130.0
150.0
163.0
188.0
8
8
8
8
.07
.06
3007(1)
3008(1)
10 VOLT RATING AT 85°C
3.9
4.7
A
A
T216A395K010CS
T216A475K010CS
.3
.4
6.0
7.0
7.5
8.8
4
4
4
4
1.00
.90
3009(1)
3010(1)
27.0
33.0
39.0
B
B
B
T216B276K010CS
T216B336K010CS
T216B396K010CS
2.0
2.5
2.5
40.0
50.0
50.0
50.0
63.0
63.0
6
6
6
6
6
6
.25
.24
.24
3011(1)
3012(1)
3013(1)
82.0
100.0
120.0
C
C
C
T216C826K010CS
T216C107K010CS
T216C127K010CS
4.0
5.0
6.0
80.0
100.0
120.0
100.0
125.0
150.0
6
8
8
6
8
8
.12
.11
.10
3014(1)
3015(1)
3016(1)
180.0
220.0
D
D
T216D187K010CS
T216D227K010CS
9.0
10.0
180.0
200.0
226.0
250.0
8
8
8
8
.08
.07
3017(1)
3018(1)
(1) To complete, insert S for sleeved or U for unsleeved, if “U” ordered also use C-0100.
