TANTALUM HERMETICALLY SEALED / AXIAL — MIL-C-39003 KEMET®
T252 (CSR33) SERIES
Available from 1.2 µF to 1000 µF, 6VDC to 50 VDC, these
high capacitance-to-volume ratio, hermetically sealed
solid tantalum capacitors are offered in standard MIL style
A, B, C, and D cases. They meet or exceed the environ-
mental and mechanical requirements of MIL-C-39003.
Designed to operate from -55°C to +125°C, they exhibit
exceptionally low DC leakage, dissipation factor and
impedance characteristics. They are ideal for coupling,
bypass, filtering and timing circuits, and are excellent
substitutes for wet tantalums in low voltage applications.
They are available in style CSR33 (T252 Series) per MIL-
C-39003/06.
CAPACITOR OUTLINE DRAWINGS
1.50±.250
(38.10±6.35)
L
1.50±.250
(38.10±6.35)
D
+
B
C
DIMENSIONS — INCHES & (MILLIMETERS)
UNINSULATED
INSULATED
D
L
D
L
B
C
MAX.
CASE
SIZE
±0.005
(±.13)
±0.031
(±.79)
±0.010
(±.25)
±0.031
(±.79)
±0.002
(±.05)
A
B
C
D
0.125 (3.18)
0.175 (4.45)
0.279 (7.09)
0.341 (8.66)
0.250 (6.35)
0.438 (11.13)
0.650 (16.51)
0.750 (19.05)
0.135 (3.43)
0.185 (4.70)
0.289 (7.34)
0.351 (8.92)
0.286 (7.26)
0.474 (12.04)
0.686 (17.42)
0.786 (19.96)
0.020 (.51)
0.020 (.51)
0.025 (.64)
0.025 (.64)
0.422 (10.72)
0.610 (15.49)
0.822 (20.88)
0.922 (23.42)
ORDERING INFORMATION
T 252 A 125 K 050 M S C*
TANTALUM
SPECIFICATION
All capacitors are sleeved unless
specified.
SERIES
252 — CSR33
CASE SIZE
LEAD MATERIAL
A / B / C / D
S — Standard
PICOFARAD CODE
FAILURE RATE**
GRADED
B — 0.1%/k hrs.
C — 0.01%/k hrs.
D — 0.001%/k hrs.
First two digits represent significant figures.
3rd digit specifies no. of zeros to follow.
EXPONENTIAL
M — 1%/k hrs.
P — 0.1%/k hrs.
R — 0.01%/k hrs.
S — 0.001%/k hrs.
CAP. TOLERANCE
M — ±20%
K — ±10%
J — ±5%
VOLTAGE RATING
*Part Number Example: T252A125K050MS (14 digits - no spaces)
At 85°C
For Military Marking Information, see page 4.
KEMET Electronics Corporation, P.O. Box 5928, Greenville, S.C. 29606 (864) 963-6300
